8 x 4 Video Cloth System (inc. Flightcase)
The LEDJ Animation system allows creation of video effects with flexible, lightweight drapes. Display low to medium resolution still images, videos, and flash animations. Individual images can be configured across multiple drapes with single control to produce large animated surfaces. The curtains are finished with hook and loop fasteners for easy panel joining in any direction.
Features
File formats:- SWF, AVI, WMV, MPG, MPEG, ASF, MPV, MPA, VCD, RM, RA and RMJ video files- BMP, JPG, GIF, PCX, WMF, ICO and PNG
- Text
Main/Sub Controller:
- One main controller can run up to 60 sub
-controllers
- Main controller features DVI input (accepts HDMI over DVI)
- Video resolutions: 1024 x 768, 800 x 600, 1280 x 768, 1600 x 1200
- Refresh rates: 60Hz, 70Hz, 72Hz, 75Hz, 80Hz
- Sub-controller: four outputs, each 2560 pixels, 10240 total
Computer Specifications:- Operating System: Windows XP, Vista, Windows 7, Windows 8 and Windows 10
- Hardware min requirements: CPU 1.5GHz, 512MB RAM, 100M network card- Pixel pitch: 100mm
Specification
- Starcloth Dimensions: 8 x 4m- Starcloth Weight: 50kg
- Main Controller Dimensions: 44 x 494 x 180mm
- Main Controller Weight: 2.6kg
- Sub Controller Dimensions: 44 x 484 x 220mm
- Sub Controller Weight: 3.4kg
- Power Box Dimensions: 56 x 350 x 320mm
-Power Box Weight: 4.5kg (each)
- Flightcase Dimensions: 930 x 1115 x 690mm
- Flightcase Weight: 35kg
