MA 135 100V 35W Mixer Amplifier

A compact, desktop mixer amplifier suitable for small offices, retail spaces and garage forecourts. Featuring two microphone inputs via 6.35mm (¼” jack) each with independent level controls, two switchable stereo audio inputs and a three band tone control. To facilitate paging, the amplifier features a switchable priority override for MIC 1.

Features

- 3 year warranty

- 100V and low impedance 4-16Ω loudspeaker output

- Two unbalanced microphone inputs via 6.35mm (¼” jack) each with independent level controls

- Switchable priority for MIC 1

- Phono/AUX inputs (switchable) with level control

- Three band tone control (150Hz, 1kHz, 6kHz) ±10dB

- Master volume control

- Screw terminal loudspeaker outputs with touch proof cover

- Captive power connection

- Convection cooled for silent operation

Specification

- Power output: 35Wrms (80W peak)

- Speaker outputs: 100V and 4-16Ω

- Microphone sensitivity: -55dB (±2dB)

- Aux input sensitivity: -20dB (±2dB)

- Frequency response: 100Hz-18kHz (±3dB)

- Tone control: ±10dB

- S/N ratio: >55dB- THD: <1% (@1kHz 1W output)

- Power consumption: 38W (max.)

- Power supply: 240V AC 50Hz- Fuse: T800mA 250V

- Dimensions: 84 x 320 x 235mm

- Weight: 5kg
