Focus Spot 4Z

The ADJ Focus Spot 4Z is a 200W LED Moving Head spot with motorized focus and motorized zoom allowing for a variable beam angle from 11 ~ 22-degrees. In addition, ADJ has fitted the Focus Spot 4Z with one GOBO wheel with rotating, replaceable GOBOs, 8 colors plus white and two prims effects: rotating 5-facet linear prism and 6-facet circular prism.

Product Description

Preliminary information

– More info coming soon

• 200W Cool White LED Engine (50,000 hr.)

• 8 Colors + white

• 6 Rotating, Replaceable GOBOs + Open

• Zoom Range: 11 ~ 22-degrees

• Focus: Motorized

• 2 Prism FX: Rotating 5-facet Linear & rotating 6-facet Circular

• powerCON In/Out to daisy chain power

• 3-pin DMX In/Out

• USB firmware update port

• Multiple DMX Control Channel Modes

• Fine Pan & Tilt: 16-Bit

• Dimming & Fine Dimming (16-Bit) : 0-100% Electronic

• 6 Dimming Modes: Standard,

• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)

• Dimensions (LxWxH): 17.67” x 11” x 6.85” / 449 x 280 x 174mm

• Weight: 18.29 lbs. / 8.3 kg.

Download Manual.pdf
