Focus Spot 2X

The ADJ Focus Spot 2X is a 100W LED Moving Head with a 3W UV LED included for black lighting or additional color hues. It features two prism effects; a 6-facet circular prism and a 6-facet linear prism. In addition, ADJ has fitted the Focus Spot 2X with a GOBO wheel with replaceable, rotating and indexable GOBOs. The GOBOs are easy to replace by removing the top housing with one screw that’s on a hinge. GOBOs easily lock in and out of the GOBO wheel. This mover is also equipped with motorized focus, Gobo Indexing, EZ Gobo replacement and a manual zoom knob near the lens to change the beam angle from 16 ~ 19 degrees.

The Focus Spot 2X is extremely versatile and has everything clubs, theaters, churches, concert productions and lighting professionals are looking for in a LED spot moving head. It has 16 & 18 DMX channel modes, Pan/Tilt Inversion, 16-Bit Fine Pan/Tilt, 3-pin DMX In/Out, locking In/Out power connectors, and a 4-Button DMX LCD menu.

The Focus Spot 2X is fitted with 8 colors plus spot and split colors. It has 6 rotating, replaceable GOBO patterns plus spot. The color wheel and GOBO wheel work independent of each other. All GOBOs are indexable.

Product Description

Light Source:

• 1 x 100W Cold White LED (7600˚K, 50,000 hr.)

• 1 x 3W UV LED

Features:

• Motorized Focus

• Manual Zoom knob on head: 16 ~ 19-degree beam angle

• Fan cooled• Strobe/Pulse effect; random strobe slow to fast

• UC IR and Airstream IR compatible (Sold Separately)

Color Wheel:

• 8 Colors + White & Split Colors

GOBO Wheel:

• 6 Rotating, replaceable Gobos + Spot

• Gobo Size: Outer: 23.8mm/Inner:19mm/Thickness: 0.2mm

• Gobo Indexing

• EZ Gobo replacement with hinged head cover

• Gobo Shake effect

Prism Wheel:

• 6-facet circular prism

• 6-facet linear prism

Control:

• 3 Operational Modes: Sound Active, Show Mode, & DMX Controlled

• Master / Slave-able

• 4 Built-in lighting shows

• 16 & 18 DMX channel modes

• Electronic Dimming: 0% - 100%

• 5 Dimmer Curves

• 4-Button DMX LED menu

• Stepper motors with micro stepping

• With Wired Digital Communication Network

Connections:

• 3-pin DMX In/Out

• Power Twist locking power In/Out connections on rear to daisy chain power (up to 9 Focus Spot 2X’s @ 120V and 16 Focus Spot 2X’s @ 230V)

Pan/Tilt:

• Fast and precise Pan/Tilt Movements

• 16-Bit Fine Pan/Tilt control

• Pan: 540-degree

• Tilt: 270-degree

• Pan/Tilt Invert Mode

• 4 Built-In Pan/Tilt Target Modes

Electrical:

• Multi-voltage Operation: 100-240V, 50Hz/60Hz

• Power Consumption: 175W

Dimensions / Weight:

• Dimensions (LxWxH): 9.33” x 9.10” x 15.15”/ 237 x 231 x 385mm

• Weight: 14.5lbs. / 6.5kgs.

What’s Included:

• Includes Omega bracket for truss mounting

• Includes Power Twist power cable

Download Manual.pdf

DMX Traits.pdf

Cut Sheet.pdf
