IS26T-WP

PASSIVE 2-WAY SPEAKER

MAX SPL 124 dB

FREQUENCY RESPONSE [-6dB]: 80 Hz - 20,000 Hz

HF: 1x 1", 1.7" v.c.LF: 2x 6.5", 1.7" v.c.

IP55 CERTIFIED

ROTATABLE HORNWEIGHT: 15.5 kg (34.17 lbs.)

Compact, with a high linear response, IS26T-WP offers maximum sound pressure and condenses the best of the dBTechnologies acoustic experience in the most versatile solution of the entire IST-WP range.

The model is characterized by two different coverage options: a standard constant dispersion of 60x90° or a 100°x15° pattern, which, thanks to the waveguide, easily transforms IS26T-WP from a point source to a line array system.

Benefiting from all the main features of the series, such as invisible mounting points and IP55 protection, this professional passive solution uses the concept of maximum versatility, allowing dozens of different configurations achievable with the accessories of the VIO X206 system.

IS26T-WP retains the minimal design of the entire series, with the possibility of customizing the color finish of the white version by yourself.

The IS-26T-WP is available in two distinct versions, each offering a different constant directivity horn to suit various installation needs:

IS-26T-WP 100x15 – featuring a 100° (horizontal) x 15° (vertical) dispersion pattern for wide coverage in horizontal deployments.

IS-26T-WP 60x90 – offering a 60° (horizontal) x 90° (vertical) dispersion for focused projection and vertical mounting scenarios.

In both versions, the horn is rotatable, allowing maximum flexibility in adapting the dispersion to the installation requirements.

Speaker Type        Passive 2-way Speaker

RMS Power        250 W

Peak Power        1000 W

Frequency Response [-6 dB]        80 Hz - 20,000 Hz

Impedance        8 Ohm

Sensitivity 1W@m        94 dB

Max SPL        124 dB

HF        1x 1", 1.7" v.c.LF2x 6.5", 1.7" v.c .

IS26T Dispersion        60x90° [rotatable horn]

X-Over Frequency        1200 Hz (internal X-Over)

Connections        Screw terminal block (IN+ | IN- | OUT+ | OUT-)

Housing        Plywood, polyurea finish

Rigging points        2x M10 threaded nut (top and bottom

IP rating        IP 55

Width        210 mm (8.3 in)

Height        650 mm (25.6 in)

Depth        270 mm (10.6 in)

Weight        15.5 kg (34.17 lbs)
